Square D HOM2448M125PRB Homeline 125 -Amp 24 -Spaces 48 -Circuit Outdoor Convertible main lug Plug-On Neutral Load Center
Original price was: $219.00.$197.10Current price is: $197.10.
- The Square D Homeline 125 Amp 24-Space 48-Circuit Outdoor Convertible Main Breaker Load Center for Plug-on Neutral breakers is UL listed for residential and commercial power distribution
- Includes a fully distributed neutral bar, allowing for the installation of Homeline Plug-on Neutral combination arc fault breakers on any space
- Each pole space accepts full-size, tandem or quad breakers
Square D HOM2448M125PRB Homeline 125 -Amp 24 -Spaces 48 -Circuit Outdoor Convertible main lug Plug-On Neutral Load Center
- The Square D Homeline 125 Amp 24-Space 48-Circuit Outdoor Convertible Main Breaker Load Center for Plug-on Neutral breakers is UL listed for residential and commercial power distribution
- Includes a fully distributed neutral bar, allowing for the installation of Homeline Plug-on Neutral combination arc fault breakers on any space
- Each pole space accepts full-size, tandem or quad breakers
- Ground and neutral bars accept up to (3) #10-14 equipment grounds
- Includes a rainproof outdoor cover
- Accommodates plug-on secondary surge arrestor (sold separately)
- Main feeders terminate from the top, feeders can enter from any direction, however, device cannot be rotated
- Rated 120/240 VAC and 22,000 AIR short circuit current rating
| Â General | |||
|---|---|---|---|
| Manufacturer Color/Finish | Gray | Type | Convertible main lug |
| Series Name | Homeline | ||
| Â Dimensions | |||
| Depth (Inches) | 4.52 | Width (Inches) | 14.75 |
| Height (Inches) | 29.86 | ||
| Â Features | |||
| Amperage | 125 | Orientation | Over/Under |
| Buss Bar Construction | Aluminum | Paintable | No |
| Circuits | 48 | Phase Type | Single phase (120/240) |
| Cover Included | Yes | Plug-On Neutral | Yes |
| Feed-Through Lugs | No | Usage | Service entrance |
| Ground Bar Installed | No | Use Location | Outdoor |
| Mounting Type | Surface | Value Pack | No |
| Number of Spaces | 24 | ||
| Â Compatibility | |||
| Brand/Model Compatibility | Square D Homeline Brand Only |
