Siemens HF361 Heavy Duty 30 Amp 600-Volt 3-Pole Indoor Fusible Safety Switch
$149.90
- Suitable for use as service entrance equipment
- Not suitable on 1200 Amp solidly grounded wye systems
- Easy 2 or 3 point mounting
Siemens HF361 Heavy Duty 30 Amp 600-Volt 3-Pole Indoor Fusible Safety Switch
Heavy Duty Safety Switches are available in 30-1200A ratings and in Type 1, 3R, 12, and 4X enclosures. Both fusible and non-fusible versions are offered. They can be used on circuits that are rated through 200K when protected by or used with Class R or J fuses. They feature quick make and break operation and visible blade construction.
- 30-Amp, 3-pole, 3-wire, 600-Volt fusible safety switch
- NEMA type 1: enclosure is intended for indoor use primarily to provide protection against contact with the enclosed equipment in locations where unusual service conditions do not exist
- Quick-make, quick-break operating mechanism that ensures positive operation
- Visible blade, double-break switching action
- Arc chutes dissipate heat and prolong switch life
- Highly visible red handle grip is designed for hook stick operation
- Defeatable dual cover interlock
- Center punch provided for field drilling to allow ON padlocking
- Generous top, bottom and side gutters that meet or exceed NEC wire-bending space requirements
- Tangential knockouts for easy conduit lineup
- Side-hinged door that opens past 180° for easier wiring
- Unique enclosure design increases rigidity and prevents cuts and scrapes to conductors and installer’s hands
- Spring reinforced fuse clips that assure reliable contact for cool operation
- Door latch securely holds door closed and allows cover padlocking
- Front removable mechanical lugs that are suitable for CU/Al 60° or 75° C conductors
- Lugs are field convertible to copper body and to a wide variety of compression connectors
- Hinged clear line terminal shield with probe holes for inspecting or testing line side terminals
- Drawn cover for increased rigidity and resistance to abuse
Dimensions
| Product Depth (in.) | 18.30 in | Product Height (in.) | 7.70 in |
|---|---|---|---|
| Product Width (in.) | 11.10 in |
Details
| Automatic/Manual | Manual | Electrical Product Type | Safety Switch |
|---|---|---|---|
| Features | Mountable, On/Off Switch, Overload Protection, Short Circuit Protection | Fused | Fused |
| Indoor/Outdoor | Indoor | Maximum Amperage (amps) | 30 |
| Maximum Wattage | 0 | NEMA Configuration | NEMA 1 |
| NEMA Configuration Receptacle | No Receptacle | Phase Type | 3 Phase |
| Power Distribution Features | Fusible | Product Weight (lb.) | 12.50 lb |
| Voltage (volts) | 600 |
Warranty / Certifications
| Certifications and Listings | UL Listed | Manufacturer Warranty | 1 YEAR |
|---|
Manuals and Support
| Brand |
|---|
