ProLine Series BR001034050R 1 in. OD x 3/4 in. ID x 50 ft. Braided Clear Vinyl Tubing
The 1-in. OD x 3/4 in. ID x 50 ft. Braided Clear Vinyl Tubing from ProLine is has 4-times the working pressure of single wall PVC tubing. This tubing is the perfect choice for severe operating conditions. Trimming or cutting is easy. This tubing can be connected using barbed fittings and connectors then secured with hose or wire clamps.
- Polyvinyl chloride reinforced with polyester braiding
- Resistant against acids, alkalis and many solvents
- Flexible
- Good for hydraulic, pneumatic and vacuum lines
- Hardness: shore a, durometer 83-plus/minus-3
- Handles a wide array of chemicals, gas and liquids
Dimensions
| Actual inside diameter (in.) | .75 | Actual outside diameter (in.) | 1 |
|---|---|---|---|
| Nominal Inside Pipe Diameter (In.) | 3/4″ | Pipe Wall Thickness (In.) | .25 |
| Product Length (ft.) | 50 ft |
Details
| Application | Air, Non-Potable Water | Color Family | Clear |
|---|---|---|---|
| Color/Finish | Clear | Connectivity | Barb |
| Material | Vinyl | Maximum Flow Rate (gallons per minute) | 35 |
| Maximum working pressure (psi) | 250 | Maximum Working Temperature (F) | 175 |
| Minimum working temperature (F) | -40 | Pack Size | 1 |
| Pipe Features | Chemical Resistant, Corrosion Resistant, Flexible | Pipe or Fitting Product Type | Pipe & Tubing |
| Product Weight (lb.) | 9.5 lb |
